5-6 Ton Electric Power Steering Lithium-Ion Tractor
Product Introduction：
1. Eco-Advantage
①Zero Emissions: 100% electric (no exhaust, ideal for indoor/outdoor use)
②Ultra-Quiet: <65 dB noise level (compared to >85 dB for diesel)
2. Powerful Performance
①High-Capacity Lithium Battery:
②80V/300Ah for 8-10 hours runtime
③Fast charging (1.5h to 80%)
④Strong Towing Force: 12 kN drawbar pull (6,000 kg capacity)
⑤3-Wheel Stability: Front steering + rear drive for precise control
3. Smart Operation
①Electric Power Steering (EPS):
✓50% easier steering vs. hydraulic systems
✓Auto-centering function
②One-Hand Control: Simple joystick for forward/reverse
③3 Speed Modes: Adjustable for different load conditions
4. Safety & Reliability
①Anti-Rollback Protection: Holds position on slopes
②Emergency Cutoff: Instant stop button + deadman switch
③Overload Alarm: Auto-stops if capacity exceeded
5. Low Maintenance
No Engine/Oil Changes: Saves 60% maintenance cost vs. diesel
Sealed Electronics: IP65 rating (dust/water resistant)Technical Parameters:
Model | Unit | QYD50S-F3Li | QYD60S-F3Li |
Rated Towing Weight | kg | 5000 | 6000 |
Maximum Tractive Force | N | 8000 | 8100 |
Overall Dimensions | mm | 2100*1080*1410 | |
Maximum Travel Speed (Loaded/Unloaded) | km/h | 10/15 | |
Maximum Gradeability (Loaded/Unloaded) | % | 6/20 | |
Product Uses：
1.Manufacturing & Production
①Assembly Line Material Handling--Efficient transfer of components between workstations
②Workshop Logistics--Continuous feeding of raw materials to production areas
③Finished Product Transport--Movement of completed goods to packaging/shipping zones
2.Logistics & Distribution
①Warehouse Operations--High-intensity horizontal transportation in distribution centers
②Dock Operations--Trailer loading/unloading at logistics yards
③Cross-Docking--Rapid transfer between inbound/outbound vehicles
3. Specialized Environments
①Cold Chain Applications--Temperature-controlled transport in refrigerated facilities
②Cleanroom Operations--Contamination-sensitive material handling
③Night Shift Operations--Low-noise, zero-emission nighttime material movement
